Giant glass light

Nozzle—A

Giant glass light

Nozzle—B

Small glass

Nozzle—C

Small glass

Nozzle—D

Micro glass

Nozzle—E

Micro glass

Nozzle—F

No wind outside

best effect

Spray height (m)

2.5-3.0

2.1-2.5

1.8-2.2

1.5-2.0

1.0-1.5

0.8-1.2

Spray distance (m)

6.5-8.0

4.0-5.2

2.6-3.0

1.8-2.5

1.2-1.8

1.0-1.5

No wind indoor

best effect

Spray height (m)

2.5-4.0

2.1-2.7

1.8-2.4

1.5-2.1

1.0-1.6

0.8-1.3

Spray distance (m)

7.0-8.5

4.5-5.8

3.0-3.5

2.0-2.8

1.5-2.0

1.2-1.7

Water supply

Claim

Pressure (kg)

2.3

1.5

1

0.4

0.3

0.2

Flow rate (L/min)

230

85

40

15

10

7

Water quality

A clean water source must be provided to ensure that the water column fountain can maintain a good laminar flow effect and lighting effect.

Water supply pipe diameter and material

DN40" steel wire hose

Built-in light in the print head

Source power requirements

24V/AC,

50W

12V/AC,

35W

12V/AC,

35W

12V/AC,

15W

4.5V/DC, 3W

4.5V/DC, 2W

Outlet diameter (mm)

twenty two

18

12

8

5

3

Nozzle well size (m) L*W*H

12*12*1.0

8*8*0.6

6*6*0.4

4*4*0.4

3*3*0.4

1.5*1.5*0.4

Pay attention

Matter

1. The water column nozzle well is preferably a dry pool. If it is a pool, the water level cannot exceed half of the nozzle. The nozzle well needs to provide two power lines.

2. The water column fountain has no wind resistance, so pay attention to the use environment.

3. The water supply pipe 2 meters in front of the nozzle cannot have elbows (with hoses) and valves, and must provide a stable water flow.

4. The light source of the water column fountain must be synchronized with the water spray or delayed opening, and the closing must be advanced or synchronized.
